Qlogic SANbox 5802 20 Port 8Gb Fibre Channel SAN Switch 2x 120W PSU
Notified by email when this product becomes available
£135.99
Qlogic SANbox 5802 20 Port 8Gb Fibre Channel SAN Switch — Refurbished Network Switch
Upgrade your network infrastructure without the premium price tag. This refurbished Bluecybercow network switch is professionally tested and ready for deployment. Whether you are expanding a small business network or upgrading a server room, this switch delivers enterprise-grade performance at a fraction of new cost. Comes with 12-month warranty and free next-day delivery.
Full Specifications
Qlogic SANbox 5802 20 Port 8Gb Fibre Channel SAN Switch 2x 120W PSU>
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">Overview
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">SANbox 5802V 20-Port 8Gb Fibre Channel Stack Switch from Q-Logic is a versatile switch designed to grow with your business. With 20 activated 8Gb device ports it's ready to manage a number of devices right out of the box. The four dedicated 10Gb stacking ports allow fast and flexible growth as the needs of your business increase, and can also be upgraded to 20Gb without rewiring or replacing any hardware.
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">The switches are designed so that multiple stacked switches can be managed as one, and the switches are compatible with a wide variety of software, including Enterprise Fabric Suite and SANdoctor. Fabric Security and QuickTools software are included with the switch. The SANbox 5000 series of switches are designed to grow with your business, reducing waste and keeping initial costs low.
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">Next-Generation Stacking: A Good Idea Gets Better!
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">SANbox 5802V lets you connect 8Gb, 4Gb, or 2Gb devices to a SAN for about the same cost as competing 4Gb-only solutions -- but the investment protection advantages go much deeper! Unlike other solutions, the 5802V offers the ability to phase bandwidth provisioning incrementally within your ISL fabric, the most performance-critical area of the SAN.
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">Start with "Always On" 10Gb ISLs
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">Each SANbox 5802V ships with all four 10Gb stacking ports active by default. At their default 10Gb setting, the four stacking ports provide over 50Gb additional bandwidth per switch -- the equivalent of six extra 8Gb ports. 10Gb ISL speed provides more than enough bandwidth for customers in the early stages of their 8Gb migration, when many switch ports will still be attached to 4Gb storage and other legacy devices.
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">20Gb Bandwidth On-Demand
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">When a majority of SANbox device ports are eventually connected to actual 8Gb devices, additional inter-switch bandwidth may be desired. At that point, customers may non-disruptively upgrade the ISL ports on one or more switches to 20Gb, extending the stability, cost-savings, and performance benefits. IT managers now have all the network headroom they need to deploy new applications and technologies with confidence. Since 20Gb uses the same cables/connectors as 10Gb, customers can upgrade their entire SAN at the click of a mouse -- without touching a cable or purchasing any new hardware.
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">Specification
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">Performance
style="box-sizing: inherit; color: rgb(34, 34, 34); font-family: Arial; font-size: 18.6667px;">
-
Ports:-
20x 8Gbps (activated)
-
4x 10Gbps Stacking Ports (Upgradable to 20Gbps)
-
Speed: 8Gbps
-
Aggregate Bandwidth: 544Gbps per chassis, end-to-end
-
Switch Latency: Fabric latency less than 0.2 µs
-
Maximum Frame Size: 2148 bytes (2112 byte payload)
-
Scalability:-
Multi-switch fabric support for all topologies including: stack, cascade, cascaded loop, and mesh
-
Multiple 10/20Gb or 8Gb links between switches
-
Adaptive trunking, intelligent path selection
-
Management Interface:-
QuickTools web applet
-
Enterprise Fabric Suite 2007
-
Command Line Interface
-
API, GS-4 Management Server (including FDMI), SNMP, RADIUS, FTP, TFTP, SMI-S
SPECIFICATIONS:
-
QuickTools web applet
-
Multi-switch fabric support for all topologies including: stack, cascade, cascaded loop, and mesh
-
20x 8Gbps (activated)
Ideal For
- Small business networks — connect office PCs, printers, phones, and access points
- Server rooms — reliable backbone switching for rack environments
- IT labs and testing — learn networking, practice for certifications
What is Included
- Qlogic SANbox 5802 20 Port 8Gb
- Power cable
- 12-month return-to-base warranty
- Free next-day delivery (UK mainland)
